Like all Mackie mixers, the 1604-VLZ PRO is designed for rugged, 24-hour-a-day use. It is a supremely flexible mixer, not just because of its multiple input/output configurations, but because of its true 4-bus architecture, 6 aux sends (with 3-4/5-6 shift switch), and extensive routing capabilities. No matter what the application, the 1604-VLZ PRO can be configured for optimal use.
16 low noise/high headroom XDR™ (Extended Dynamic Range) XLR mic inputs
16 balanced/unbalanced mono line inputs
True 4-bus design
Inserts on all channels
Direct outs on channels 1–8
3-band EQ with sweepable mids
|Mic Preamp-Max Input||+22dB|
|Mic Preamp-Input Impedance||1.3kΩ|
|Main Mix Noise-Main Mix down, ch. faders down||–90.5dB|
|Total Harmonic Distortion (THD)||0.005%|
|Attenuation-Channel fader down||–85dBu|
|Frequency Response-20Hz to 60kHz||+0dB/–1dB|
|Frequency Response-20Hz to 100kHz||+0dB/–3dB|
|Max Levels-All other inputs||+22dBu|
|Max Levels-Main Mix 1⁄4” TRS outputs||+28dBu|
|Max Levels-All other outputs||+22dBu|
|EQ-High Shelving||±15db @ 12kHz|
|EQ-Mid Peaking||±15dB, sweep 100Hz–8kHz|
|EQ-Low Shelving||±15db @ 80Hz|
|Power Consumption||120VAC, 50/60Hz, 25 Watts|
|Power Consumption||20 lbs.|
|Dimensions||17.6″ x 19″ x 5.0″|
