BEMATRIX LEDSKIN 2.5MM

With these 2.5mm LEDskins, the design possibilities are endless. Must be used with beMatrix frame systems.

  • microchip

    The LEDskin® cabinets can be mounted and dismantled very easily in the frame system by using manual M8 connectors.

  • microchip

    The LEDskin® cabinets are automatically aligned thanks to the built-in magnets.

  • microchip

    The quick lock system guarantees that all the cabinets stay in place.

  • microchip

    The beMatrix cover solutions can be used to create a clean and finished look of the LEDskin® walls.

  • microchip

    Ability to hide all the electrical cables by using textiles and colored panels.

Get a Quote

TECH SPECS

Pixel Pitch 2.583 mm
Tile Size 496 x 496 x 62 mm
Brightness 1200 nits
Contrast 2000:1
Pixel Per Inch 9.832 ppi
LED Technology SMD 1515 matte LED
Aspect Ratio 1:1
Weight 16 lb
Max Power Consumption 100 watts
Viewing angle 110° horiz – 110° vert
Native Resolution 192 x 192 px
Minimum Convex Radius N/A
Minimum Concave Radius N/A
